Technical Overview
Overall Appliance Dimensions (HxWxD) (in)
32 3/16'' x 23 9/16'' x 21 5/8''
Silence Level
42 dB(A) re 1pW
Additional information
Optimal protection for sensitive glassware by low temperature drying with zeolite, optimized basket design and intelligent water softening
8 programs with aqua sensor and 6 options, such as Power for cleaning and drying dishes in 57 minutes and Intensive for particularly thorough cleaning in the lower basket
Flexible basket system with smooth running rails on all levels and cushioned closing of the upper and lower baskets
Perfectly illuminated interior
Push-to-open function for perfect integration into custom cabinet fronts
Flexible hinge for reduced toe-kick height as of 1 15/16" (50 mm)
Lateral Info-Light
Very quiet: 42 dB
TFT display indicating remaining or end time, refill for salt and rinsing agent, inflow of water.
Touch key operation.
Flexible cycle time reduction, even during an active cycle.
Personalization function for storing individual combinations of programs.
Temporary noise reduction (only available with active Home Connect functionality).
Information key with use indicators.
Sanitized indicator in the control panel.
Time delay up to 24 hours.
Visual and acoustic end of program indicator.
Lateral Info-Light.
Perfectly illuminated interior.
Glass protection with zeolite.
Aqua sensor.
Load sensor.
Automatic detergent function.
Regeneration electronics.
Flow-Through Water Heater™
Triple filter system.
Soft lock.
Aqua stop.
Home network integration for digital services (Home Connect) wireless via WiFi.
The use of the Home Connect functionality depends on the Home Connect services, which are not available in every country. For further information please check: home-connect.com.
8 programs:
Auto 150-160 °F. Auto 127-140 °F. Auto 113-122 °F. Eco 113-136 °F. Wash and Dry 122°F. Quick Wash 113 °F (30 min). Glass Care 122 °F. Personalization function (default setting: Pre-rinse).
6 options:
Remote Start Intensive. Power. Sanitize. Extra Dry with zeolite.
Machine Care.
Flexible rack system with smooth running rails on all levels and soft-closing system of the upper and lower rack.
3rd rack for cutlery.
Upper basket:
Over extension. Optional extra cleaning area by activating additional spray nozzles. Rackmatic with 3 levels, adjustable in height up to 2" (5 cm). 6 folding spines. 4 folding racks for optimal protection of glass.
Lower basket:
8 folding spines. 2 folding racks for optimal protection of glass. Dividable glass support.
Cutlery basket.
Holder for long-stemmed glasses.
13 place setting capacity.
Maximum glass loading capacity 23 wine glasses.
Energy Star certified
Total annual energy consumption 269 kWh.
Noise level 42 dB (re 1 pW).
Height-adjustable feet.
Appliance toe-kick recess 3 15/16" (see drawing).
Rear feet adjustable at front.
Door weight up to 24 lb.
Door panel dimension dependent on toe-kick height of kitchen cabinetry.
Installation and usage also with custom cabinet handle possible. The push-to-open function remains active.
Total rating: 1440 W.
Connecting cable 47 1/4" with three-prong plug (NEMA 5-15P).
Connection to hot or cold water possible.
