400 SeriesRemote fan unitsAR400143
Remote fan units

400 series Remote fan unit
AR400143

1 / 4
Photo Nr. 1 of the product AR400143
Photo Nr. 2 of the product AR400143
Photo Nr. 3 of the product AR400143
Photo Nr. 4 of the product AR400143
Photo thumb Nr. 1 of the product AR400143
Photo thumb Nr. 2 of the product AR400143
Photo thumb Nr. 3 of the product AR400143
Photo thumb Nr. 4 of the product AR400143
Photo thumb Nr. 1 of the product AR400143
Photo thumb Nr. 2 of the product AR400143
Photo thumb Nr. 3 of the product AR400143
Photo thumb Nr. 4 of the product AR400143

400 series Remote fan unit
AR400143

Find a local Dealer
Find a local dealer in your vicinity

Check appliance compatibility

How to find your E-Number
The model number (E-number) is located on the type plate of your device.

Technical Overview

Product group for which the accessory is available
Hood

Special Features

Powerful remote fan unit to combine with motorless appliances
Efficient BLDC technology
Compact, space-saving installation in the chimney of AI/AW 442
Power levels depend on the motorless appliances, see table on page XX.
3 electronically controlled power levels and one intensive mode.

Specifications

Powerful remote fan unit to combine with motorless appliances
Efficient BLDC technology
Compact, space-saving installation in the chimney of AI/AW 442
Power levels depend on the motorless appliances, see table on page XX.
3 electronically controlled power levels and one intensive mode.
Fan technology with highly efficient, brushless DC motor (BLDC).
Including sound insulation to minimise the noise level.
Steel housing, zinc-plated.
Pipe connection pieces on output side: 1x NW 150 round.
Remote fan unit in combination with the motorless AW 442.
Connection to the respective appliances via network cable.
Installation in the chimney of AW 442.
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the power supply line of the ventilation appliance needs a suitable safety switch.
Total connected load 230 W.
Connecting and network cable included in delivery.
