The model number (E-number) is located on the type plate of your device.
Technical Overview
Product group for which the accessory is available
Hood
Accessory Type
In-line Blower
Special Features
Efficient BLDC technology
Compact and space-saving due to installation in a 4-inch high toe-kick
Power levels depend on the ventilation system.
3 electronically controlled power levels and one intensive mode.
Fan technology with highly efficient, brushless DC motor (BLDC).
Specifications
Efficient BLDC technology
Compact and space-saving due to installation in a 4-inch high toe-kick
Power levels depend on the ventilation system.
3 electronically controlled power levels and one intensive mode.
Fan technology with highly efficient, brushless DC motor (BLDC).
Steel housing, zinc-plated.
Pipe connection pieces on intake side: 1 x NW 150 round.
Pipe connection pieces on output side: 1x NW 150 flat duct.
Retaining bracket for installation on the ceiling or side of a cupboard enclosed.
Connection to the respective appliances via network cable.
Installation in the plinth with cut-out for the air ducting in the furniture base.
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the power supply line of the ventilation appliance needs a suitable safety switch.
Total rating: 65 W.
100 - 120 V / 50 Hz.
Total amps: 2 A.
Connecting cable 59 1/16 without plug (hardwire required).
Network cable 2 m.
