400 series Wall Hood 48'' Stainless steel
AW442720

Find a local Dealer

Technical Overview

Installation Type
Wall-mounted
Type of extraction
air extraction / air recirculation

Specifications

Professional technology hood combined with classic Gaggenau design
Highly efficient extraction of cooking vapours due to large vapour collection area
Angled baffle filter with high grease absorption
Function for automatic, sensor-controlled power adjustment depending on the build-up of cooking vapours
Air extraction or air recirculation system
Air recirculation module with activated charcoal filter: quiet and highly efficient air recirculation solution with odour reduction as in air extraction mode and long replacement intervals
Noise level depends on the built-in situation.
3 electronically controlled power levels and 1 intensive mode.
Automatic function with sensor-controlled run-on function.
Grease filter saturation indicator.
Baffle filter, dishwasher-safe.
Lamp output 3 x LED light bars 10W.
Illuminance 1110 lx.
Easy mounting system for simple installation and alignment.
Connection to the respective appliances via network cable.
Clearance above gas appliances min. 70 cm.
Clearance above electric appliances min. 60 cm.
Air recirculation module with 2 activated charcoal filters is installed in the inner chimney. Special air recirculation chimneys are available for this.
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the power supply line of the ventilation appliance needs a suitable safety switch.
Total rating: 65 W.
120 V / 60 Hz.
