200 series Vario built-in fridge-freezer with freezer at bottom 177.2 x 55.8 cm soft close flat hingeRB289300
1 / 11
200 series Vario built-in fridge-freezer with freezer at bottom 177.2 x 55.8 cm soft close flat hingeRB289300
Find a local Dealer
Technical Overview
Energy Efficiency Class Footnote 1: Scale of Energy Efficiency Classes from A to G
D
Automatic defrosting
Fridge and freezer
Airborne acoustical noise emissions
37 dB(A) re 1pW
Freshness system
Hyper fresh premium
Home Connect Footnote 2: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
Yes
Airborne acoustical noise emission class
C
Specifications
Interior with precision-fitted, solid aluminium elements in Gaggenau Light Bronze
Extendable shelves and drawers
Warm white and glare-free LED light
Four climate zones incl. two fresh cooling drawers close to 0 °C
Four climate zones incl. two fresh cooling drawers close to 0 °C
Height-adjustable, extendable safety glass shelves, set in solid aluminium profiles
Cushioned door closing system allowing a soft and controlled door closure
Smooth running fully extendable telescopic pull out racks and a cushioned closing system allow a soft and controlled closure of the drawers
Smooth running fully extendable telescopic pull out racks and a cushioned closing system allow a soft and controlled closure of the drawers
Solid maple bottle supports with magnetic connector
Total volume 223 litres
Electronic temperature control with digital display.
Touch keys.
Automatic defrosting with defrost water evaporation.
Cushioned door closing system from 20° door opening angle, integrated in door hinge.
Open-door and malfunction system.
Holiday mode.
Remote control and monitoring.
Integrated WiFi module for digital services
(Home Connect).
The availability of the Home Connect functionality depends on the availability of the Home Connect Services in your country. Home Connect Services are not available in every country – for further information please check: www.home-connect.com
Fast cooling.
Temperature adjustable from +3 °C to +8 °C.
2 height-adjustable safety glass shelves, partly extendable.
1 frosted white glass shelf.
2 oiled, solid maple bottle supports with magnetic connector, can be increased to 5 supports per shelf.
A total of 9 bottles (based on a 0.75 l bottle) can be stored on one level using 5 bottle supports.
The bottle supports are also suitable for storing champagne bottles and magnums.
1 large aluminium door rack for bottles.
1 aluminium door rack.
Warm white interior lighting (3500 K) with integrated glare-free LED side lights.
Volume 101 litres.
Drawers with solid aluminium handles and signature drawer front with a gradual frosted surface.
1 fully extendable fresh cooling drawer close to 0 °C, illuminated.
Humidity can be adjusted manually.
Ideal for fruit and vegetables.
1 fully extendable fresh cooling drawer close to 0 °C, illuminated.
Ideal for meat, fish and poultry.
Net volume 55 litres.
No-frost technology with fast freezing.
Temperature adjustable from -14 °C to -24 °C.
4-star freezer compartment.
Drawers with solid aluminium handles and signature drawer front with a gradual frosted surface.
Defrost assistance.
Freezing capacity 7 kg /24 h.
Storage time after a malfunction 8 h.
3 freezer drawers, 1 of which extra large.
2 safety glass shelves.
Volume 67 litres.
Energy efficiency class D at a range of energy efficiency classes from A to G.
Energy consumption 201 kWh/year.
Noise level 37 dB (A) re 1 pW.
Flat hinge.
Door hinge right, reversible.
Door opening angle of 115°, fixable at 90°.
Max. door panel weight:
Upper door 19 kg. Lower door 19 kg.
Connecting cable 2.3 m with plug.
