Vario 400 SeriesFreezerRF471306
Freezer

400 series Vario built-in freezer 212.5 x 75.6 cm soft close flat hinge
RF471306

1 / 8
Photo Nr. 1 of the product RF471306
Photo Nr. 2 of the product RF471306
Photo Nr. 3 of the product RF471306
Photo Nr. 4 of the product RF471306
Photo Nr. 5 of the product RF471306
Photo Nr. 6 of the product RF471306
Photo Nr. 7 of the product RF471306
Photo Nr. 8 of the product RF471306
Photo thumb Nr. 1 of the product RF471306
Photo thumb Nr. 2 of the product RF471306
Photo thumb Nr. 3 of the product RF471306
Photo thumb Nr. 4 of the product RF471306
Photo thumb Nr. 5 of the product RF471306
Photo thumb Nr. 6 of the product RF471306
Photo thumb Nr. 7 of the product RF471306
Photo thumb Nr. 8 of the product RF471306
Photo thumb Nr. 1 of the product RF471306
Photo thumb Nr. 2 of the product RF471306
Photo thumb Nr. 3 of the product RF471306
Photo thumb Nr. 4 of the product RF471306
Photo thumb Nr. 5 of the product RF471306
Photo thumb Nr. 6 of the product RF471306
Photo thumb Nr. 7 of the product RF471306
Photo thumb Nr. 8 of the product RF471306

400 series Vario built-in freezer 212.5 x 75.6 cm soft close flat hinge
RF471306

Energy label E from G to ADatasheet
Find a local Dealer

Technical Overview

Energy Efficiency Class Footnote 1: Scale of Energy Efficiency Classes from A to G
E
Automatic defrosting
Fridge
Airborne acoustical noise emissions
42 dB(A) re 1pW
Airborne acoustical noise emission class
D
Home Connect Footnote 2: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
Yes

Specifications

Stainless steel interior with solid anthracite aluminium elements
Warm white and glare-free LED light spots
Opening assist for door with two options:
1. Push-to-open function for integration into handleless furniture front 2. Pull-to-open function to facilitate opening the door using a handle
The drawers in the fridge and freezer models are positioned at the same height.
With side-by-side installation, the glass shelves and door racks can be aligned on the same level
Material and aesthetics of interior as for RC model
- Glass shelves - Solid anthracite aluminium door racks
Flat stainless steel inner door, full-length
Smooth design rail system providing flexible positioning for shelves and door racks
Integrated ice maker with fixed inlet water connection
TFT touch display
Total volume 445 litres
TFT touch display operation.
Clear text display.
Dynamic cold air distribution.
Automatic defrosting with defrost water evaporation.
Cushioned door closing system.
Rest mode certified by Star-K.
When rest mode is active, the appliance can only be opened using a handle.
Open-door and malfunction system.
Remote control and monitoring.
Remote diagnostics.
Integrated WiFi module for digital services
(Home Connect).
The availability of the Home Connect functionality depends on the availability of the Home Connect Services in your country. Home Connect Services are not available in every country – for further information please check: www.home-connect.com
No-frost technology with fast freezing at -30 °C.
Temperature adjustable from -14 °C to -24 °C.
4-star freezer compartment.
Freezing capacity 23 kg /24 h.
Storage time after a malfunction 10 h.
4 safety glass shelves, 3 of which are individually height adjustable.
2 fully extendable drawers with transparent front.
Brilliant LED light spots with warm white, glare-free light (3500 K).
Smooth design door rail system with fully flexible positioning of door racks.
4 height-adjustable door racks.
Integrated in the freezer compartment, with fixed inlet water connection.
Particle filter for water inlet, integrated in ventilation grille area.
Saturation indicator shown in TFT touch display.
Can be switched off.
Ice cube production approx. 1.5 kg/24h.
Removable ice storage container with approx. 4.4 kg capacity.
Energy efficiency class E at a range of energy efficiency classes from A to G.
Energy consumption 321 kWh/year.
Noise level 42 dB (A) re 1 pW.
Flat hinge.
Door hinge left, reversible.
Door opening angle of 115°, fixable at 90°.
In case of door opening angle of 90°, the drawers have restricted access and the standard ice storage container cannot be removed.  A small ice storage container (RA 448 220) is available to ensure access. This change must be done prior to fixing the door.
In case of door opening angle of 90°, the drawers have restricted access and the standard ice storage container cannot be removed.  A small ice storage container (RA 448 220) is available to ensure access. This change must be done prior to fixing the door.
Max. door panel weight 29 kg.
Shut-off valve for water connection must be planned next to the appliance and always be accessible.
If the water pressure exceeds 0.8 MPa (8 bar), connect pressure relief valve between water tap and hose set.
Total connected load 0.300 KW.
Connecting cable 3.0 m, pluggable.
Water inlet.
Supply hose 2.0 m with 3/4 " connection.
Water pressure 2.4 to 6.9 bar.
