Can be integrated invisibly in upper cabinet

Energy-saving, low-noise fan

Rim extraction with flat and easy-to-clean glass cover

Dimmable, neutral white LED light for ideal illumination of the whole cooktop

Air extraction or recirculation system

Energy efficiency class A++

Performance and noise level, output level 3/Intensive:

Air output according to EN 61591. Sound power level according to EN 60704-3.

Air extraction:

540 / 730m³/h.

64 / 70 dB (A) re 1 pW.

Air recirculation:

530 / 690m³/h.

72 / 77 dB (A) re 1 pW.

Three electronically controlled power levels and an intensive mode.

Remote control is available as a special accessory.

Interval ventilation, 6 min.

Run-on function, 6 min.

Grease filter saturation indicator.

Metal grease filter, dishwasher-safe.

Glass filter cover.

Neutral white LED light (4000 K), dimmable.

Lamp output 2 x 1W LED.

Illuminance: 244 lx

Fan technology with highly efficient, brushless DC motor.

Energy efficiency class A++ at a range of energy efficiency classes from A+++ to D.

Energy consumption 29.6 kWh/year.

Ventilation efficiency class A.

Ilumination efficiency class A.

Grease filter efficiency class D.

Sound level min. 44 dB / max. 64 dB normal mode.

For air recirculation an external filter module is required.

Patented air recirculation module with activated charcoal filter can be installed in the upper cabinet. The activated carbon filter can be changed from the front by simply pulling out the filter drawer.

The door of the upper cabinet must be fully open in order to change the activated charcoal filter.

Can be integrated invisibly in upper

Vario cooktops with intensive production of vapours like VR/VP/VF should be placed in the middle beneath the cooker hood (in this case air recirculation is not recommended).

Clearance above gas appliances min. 65 cm (more than total load gas 12 kW min. 70 cm).

Clearance above electric appliances min. 50 cm.

When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the hood’s power supply line needs to feature a suitable safety switch.

Total connected load 172 W.
