The model number (E-number) is located on the type plate of your device.
Technical Overview
Product group for which the accessory is available
Hood
Accessory type
In-line blower
Special Features
Powerful remote fan unit to combine with motorless appliances
Efficient BLDC technology
Compact, space-saving installation in the chimney of AW 442
Air output according to DIN EN 61591. Sound power and sound pressure depending on built-in situation.
665 / 1005 m³/h.
Specifications
Powerful remote fan unit to combine with motorless appliances
Efficient BLDC technology
Compact, space-saving installation in the chimney of AW 442
Performance output level 3/Intensive:
Air output according to DIN EN 61591. Sound power and sound pressure depending on built-in situation.
Air extraction:
665 / 1005 m³/h.
Power levels depend on the motorless appliances, see table on page XX.
3 electronically controlled power levels and one intensive mode.
Fan technology with highly efficient, brushless DC motor (BLDC).
Including sound insulation to minimise the noise level.
Metal housing, zinc-plated.
Pipe connection pieces on output side: 1x NW 150 round.
Remote fan unit in combination with the motorless AW 442.
Connection to the respective appliances via network cable.
Installation in the chimney of AW 442.
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the power supply line of the ventilation appliance needs a suitable safety switch.
Total connected load 230 W.
Connecting and network cable included in delivery.
