Technical Overview
Product group for which the accessory is available
Hood
Accessory type
In-line blower
Special Features
Efficient BLDC technology
Compact and space-saving installation in a 10 cm high plinth
Air output according to DIN EN 61591. Sound power and sound pressure depending on built-in situation.
700 / 875 m³/h.
Power levels depend on the motorless appliances, see table on page XX.
Specifications
Efficient BLDC technology
Compact and space-saving installation in a 10 cm high plinth
Performance output level 3/Intensive:
Air output according to DIN EN 61591. Sound power and sound pressure depending on built-in situation.
Air extraction:
700 / 875 m³/h.
Power levels depend on the motorless appliances, see table on page XX.
3 electronically controlled power levels and one intensive mode.
Fan technology with highly efficient, brushless DC motor (BLDC).
Metal housing, zinc-plated.
Pipe connection pieces on intake side: 1 x NW 150 round.
Pipe connection pieces on output side: 1x NW 150 flat duct.
Retaining bracket for installation on the ceiling or side of a cupboard enclosed.
Connection to the respective appliances via network cable.
Installation in the plinth with cut-out for the air ducting in the furniture base.
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the hood's power supply line needs a suitable safety switch.
Total connected load 180 W.
Connecting cable 1.8 m, pluggable.
Network cable 2 m.
