How to find your E-Number
The model number (E-number) is located on the type plate of your device.
Technical Overview
Product group for which the accessory is available
Hood
Accessory Type
In-line Blower
Special Features
Efficient BLDC technology
Particularly quiet due to patented noise insulation
3 performance output levels and intensive mode: Air output according to EN 61591. Sound power and sound pressure depending on built-in situation.
Air recirculation: 500 CFM
Power levels depend on the ventilation system.
Additional information
Efficient BLDC technology
Particularly quiet due to patented noise insulation
3 performance output levels and intensive mode:
Air output according to EN 61591. Sound power and sound pressure depending on built-in situation.
Air recirculation:
500 CFM
Power levels depend on the ventilation system.
3 electronically controlled power levels and 1 intensive mode.
Fan technology with highly efficient, brushless DC motor (BLDC).
Including sound insulation to minimise the noise level.
Steel housing, zinc-plated.
Pipe connection piece on intake side: 1 x NW 150 flat duct.
Retaining bracket for installation at the furniture base enclosed.
Extended change interval of the activated charcoal filter: regenerable up to 30 times.
Regenerable in the oven at 400 °F
Connection to the respective appliances via network cable.
Installation in a cupboard possible with a cut-out in the furniture base or behind the cupboard positioned on the floor. Please refer to the planning information on page XX.
To replace the filter the remote fan unit must be accessible.
Total rating: 170 W.
Total Amps: 10 A.
120 V / 60 Hz.
Connecting cable 35.4" with plug.
78" network cable included.
